Heater
Return to modifications
heating oil suppliers
FAQ - lots of info here
if heater fails to start - first power off (rocker switch) then try again if it has been left for an extended period it can need this
heater - currently running on 28 second heating oil - runs equally well on diesel - 28 is usually cheaper
Isolator by main van isolator - fuse for heater is in the box that covers the main isolator

Power to the heater is from the rocker switch closest to the heater controller

to prime pump hold down the bottom 2 buttons - then arrow up -

to put into temp mode hold top right and left buttons down together - if taken out of this mode and put in frequency mode hz can be set - this sets the pump dose rate (the fan is automatically linked )
to pair remote have screen on temp - press and hold arrow up (5 sec) then press on - on remote the heater should start

Pump now located under the bonnet - seems to work well -

Eberspacher heater plugs part number E100 251384010002
