Main ignition key switch
Red - +ve
red / white - Switched
Ignition unit
Red/white - switched supply from ignition
Green - to ground
Black to coil
Alarm
Red - power supply (via hidden switch)
Black - ground
Brown - switched 12v from alarm
Currently the bike should be started / stopped on the key - can be
started from the alarm however if the alarm is de activated the
bike will still run as the dynamo will self generate enough to
keep the ignition live even though power has been cut via the
alarm
The alarm works perfectly as an alarm - the remote function was
taken off to simplify the system
